Gear pumps can suck up liquid up to a maximum of 2 meters difference in level without being charged; if the difference in level is greater, it will be sufficient to place a check valve at the end of the suction pipe and fill the latter up to the pump. To increase the suction capacity pour about 10 ml of the liquid to be siphoned into the pump. In any case, it is always important to bring the pump closer to the container of the liquid to be decanted. If the pump runs dry for more than 10 seconds there is a risk of damaging it. Never run the pump without the hose connectors. Always connect the supplied strainer to the suction hose before starting the pump. Gear pumps can be used with the dispensing gun only in conjunction with safety valve part number 920035 All models can operate in continuous service at a maximum pressure of 2 bar (0.2 MPa).
- Weight: kg 7
- Dimensions: mm 250 x 120 h 150
- Center distance between fixing holes: mm 80 x 100
- Angle between the hose holders: 180°
- Hose holder attachment diameter: mm 20
- Hose connector thread: 3/4" GAS BSP
