PEDROLLO TOP 4 1HP 220-240/50 10m H07 ELECTRIC PUMP

The TOP-FLOOR series suitable for drainage of water.

Flow rate up to 160 l/min
Head up to 9 m
Liquid temperature up to +40 °C
Depth of use below the water level up to 3 m (with power cable of appropriate length)
Passage of suspended solids up to Ø 2 mm
Emptying level up to 2 mm from the bottom

Pedrollo Top Series

Available Now

Pedrollo electric pump top4 1hp v.230 - submersible clear water drainage pump

The TOP-FLOOR series suitable for drainage of water.

Flow rate up to 160 l/min
Head up to 9 m
Liquid temperature up to +40 °C
Depth of use below the water level up to 3 m (with power cable of appropriate length)
Passage of suspended solids up to Ø 2 mm
Emptying level up to 2 mm from the bottom

Pedrollo Top Series

€221.06 (tax incl.)

€368.44 -40%

Payment methods

pagamenti

Best E-commerce in Italy for industrial supplies - la Repubblica

migliori ecommerce italia forniture industriali

24 month warranty

Do you need more information? Contact us

Description

The TOP series is suitable for drainage of clear water without abrasive particles.

The construction solutions used ensure ease of use and safe operation thanks to total motor cooling and double sealing on the shaft.

They are recommended for emergency draining of small flooded areas (rooms, basements, garages), disposal of used domestic water (dishwashers, washing machines), emptying sumps.

Features

Liquid type: clean water

Uses: domestic

Uses: drainage, drainage

Type: submersible

Family: submersibles

Performance range:

Flow rate up to 360 l/min (21.6 m³/h)
Head up to 14.50 m

Operating limits:

Liquid temperature up to +40°C

- Depth of use below the water level:
- up to 3 m for TOP 1-2-3
- up to 5 m for TOP 4-5
(with power cable of appropriate length)
(Liquid temperature up to +90 °C for service
intermittent maximum of 3 minutes)
- Passage of suspended solids up to Ø 10 mm
- Emptying level:
- up to 14 mm from the bottom for TOP 1-2-3
- up to 30 mm from the bottom for TOP 4-5
- Continuous service S1

BRAND: PEDROLLO
POWER (Kw): 0.75
ALIMENTATION (V.): 230

TOP_IT_50Hz.pdf
