ELECTRIC PUMP RXm5/40 1.5HP V.220-240
RXM5/40 pumps are suitable for drainage of dirty water.
The construction solutions used ensure safe operation, even in continuous use, thanks to total motor cooling.
The construction solutions used ensure safe operation, even in continuous use, thanks to total motor cooling.
They are recommended for domestic use, for the evacuation of dirty water in which suspended solids are present.
-
Click on the link to return to the categories of PEDROLLO SERIES RX - VORTEX SUBMERGIBLE WATER ELECTRIC PUMPS FOR SOLID WATER (comid.it)
Accettiamo i seguenti metodi di pagamento
Description
RXM5/40 pumps are suitable for drainage of dirty water.
The construction solutions used ensure safe operation, even in continuous use, thanks to the total cooling of the motor.
The construction solutions used ensure safe operation, even in continuous use, thanks to the total cooling of the motor.
They are recommended for domestic use, for the evacuation of dirty water in which suspended solids are present.
Features
Liquid type: clean water
Uses: domestic, civil
Uses: drainage, drainage
Type: submersible
Family: submersibles
-
Performance range:
- Flow rate up to 380 l/min (22.8 m³/h)
- Head up to 13 m
Operating limits:
- Liquid temperature up to +50°C
(with power cable of appropriate length)
- Passage of suspended solids: up to Ø 40 mm
-
- Emptying level:
- up to 25 mm from the bottom for RX 2/20 RX 3/20
- up to 50 mm from the bottom for RX 4/40 RX 5/40
- up to 50 mm from the bottom for RX 4/40 RX 5/40
- Continuous service S1
To guide you in your choice, see our guide to submersible pumps
48TXV25A1U
- BRAND
- PEDROLLO
- POWER (Kw)
- 1.1
- ALIMENTATION (V.)
- 230
