La valvola di intercettazione a flusso avviato DN250 PN16 ha corpo in ghisa GG25, cappello in ghisa sferoidale GGG40 e attacchi flangiati EN 1092-2. Il progetto segue la norma DIN 3356 e la manovra è a volantino manuale: è la soluzione classica per intercettare e strozzare la portata su acqua, vapore e olio fino a 200 °C.

Tipo: valvola di intercettazione a flusso avviato (tipo globo), corpo diritto
Diametro nominale: DN 250
Pressione nominale: PN 16 (16 bar)
Temperatura massima: 200 °C
Fluidi ammessi: acqua, vapore, olio
Corpo e cappello: ghisa grigia GG25 / ghisa sferoidale GGG40
Otturatore: acciaio A105 con riporto 2Cr13
Attacchi: flange EN 1092-2 PN 16 – Ø esterno 405 mm, interasse fori 355 mm, 12 x Ø28, spessore 32 mm
Interasse: 730 mm (EN 558-1 – DIN 3202 F1)
Comando: volantino manuale
Peso indicativo: 208,00 kg

Clicca sul link per tornare a Valvole a flusso avviato

La valvola di intercettazione a flusso avviato DN250 PN10 ha corpo in ghisa GG25, cappello in ghisa sferoidale GGG40 e attacchi flangiati EN 1092-2. Il progetto segue la norma DIN 3356 e la manovra è a volantino manuale: è la soluzione classica per intercettare e strozzare la portata su acqua, vapore e olio fino a 200 °C.

Tipo: valvola di intercettazione a flusso avviato (tipo globo), corpo diritto
Diametro nominale: DN 250
Pressione nominale: PN 10 (10 bar)
Temperatura massima: 200 °C
Fluidi ammessi: acqua, vapore, olio
Corpo e cappello: ghisa grigia GG25 / ghisa sferoidale GGG40
Otturatore: acciaio A105 con riporto 2Cr13
Attacchi: flange EN 1092-2 PN 10 (foratura secondo norma)
Interasse: 730 mm (EN 558-1 – DIN 3202 F1)
Comando: volantino manuale

Clicca sul link per tornare a Valvole a flusso avviato

PRODUCT IN STOCK

PED8 VT GALVANIZEDAUTOCLAVE TANK LT.1000
Z PED air cushion autoclave specifically dedicated to water lifting with the function of constituting a pressurized water lung that, when properly sized, limits the number of hourly pump starts. Product constructed of galvanized carbon steel.

CAPRARI SUBMERSIBLE PUMP E6P45-6/2I-V KW4(HYDRAULIC PART ONLY)

CAPRARI SUBMERSIBLE PUMP E6P55-6/2A-V KW4(HYDRAULIC PART ONLY)

Lowara CA 200/55/D centrifugal big-impellerelectric pump intended for both domestic and industrial use. Single-impeller (CEA) and big-impeller (CA) versions available. Available on request "V" versions with FPM elastomers for temperatures up to 110°C and "N" versions completely in AISI 316 stainless steel.
Click on the link to return to the category of Lowara AC electric pumps

The Lowara CO 500/30/D Electric Pump combines the advantages of an open impeller with those of AISI 316 stainless steel. Developed for use in industrial washing, food industry, circulation systems and fish farming. Especially recommended for handling moderately aggressive liquids.
Click on the link to return to the category of Lowara centrifugal electric pumps CO

CAPRARI SUBMERSIBLE PUMP E6XD35-4/15-V KW7.5

UseStorage of water at atmospheric pressure.MaterialNon-toxic linear low-density polyethylene suitable for drinking water or food liquids (wine, oil, milk, etc.) in accordance with EU Regulation No. 10/2011 dated 14/01/2011 and EC Regulation No. 1935/2004 dated 27/10/2004
Warranty: 2 years
CLICK ON THE LINK TO RETURN TO THE PAGE OF POLYETHYLENE WATER TANKS

Submersible sewage pumps suitable for conveying sewage with suspended solids. MAT series models are equipped with a grinder for civil and industrial sewage systems. Designed for high heads and small flow rates, they are the ideal solution for conveying civil wastewater in isolated areas far from sewer systems.

Submersible sewage pumps suitable for conveying wastewater with suspended solids. MAT series models are equipped with a grinder for civil and industrial sewage systems. Designed for high heads and small flow rates, they are the ideal solution for conveying civil wastewater in isolated areas far from sewer systems.

They are particularly suitable in pumping sewage, screened wastewater, wastewater from industrial processes, and in conveying the civil discharges of small communities or isolated dwellings.MAV backward open impeller pump that offers greater guarantees in water with solid suspensions, even filamentous ones, and more limited wear and tear due to lower speeds.
